External Sample Module
. Versatile sampling station with an integrated detector for FTIR spectrometers
. Full sized sample compartment dimensions for compatibility with PIKE accessories
. 1 x 1”1 / 4 – 20 구멍 그리드
. 장거리 가스 셀, TGA/FTIR 악세사리, PIKE 자동화 액세서리를 포함한 외부 샘플 모듈 사용에 이상적인 실험의 예
. FTIR Placement: Right or Left side
. Sample Compartment Size: W 190 x D 265 x H 155 mm
. Detector Options: DTGS, MCT, others inquire
기본구성
. 10155-10XXR External Sample Module, Right side includes optics, mounting hardware, electrical cabling for FTIR, sample compartment windows, purge tubing and fittings to connect to purge gas
. 10155-10XXL External Sample Module, Left side includes optics, mounting hardware, electrical cabling for FTIR, sample compartment windows, purge tubing and fittings to connect to purge gas
. Detector 선택 필요
선택구성
. Detector (선택 필요)
Part Number |
Description |
10155-2010 |
DLaTGS Detector for External Sample Module |
10155-2020 |
MCT Detector (mid band) for External Sample Module |
10155-2030 |
MCT Detector (narrow band) for External Sample Module |
10155-2040 |
MCT Detector (wide band) for External Sample Module |
. Replacement Windows
Part Number |
Description |
10160-1186 |
Window, KBr, 50x3mm |
10160-5030 |
Window, BaF2, 50x3mm |
10160-1165 |
Window, NaCl, 50x3mm |
제품 관련 영상
장비 관련 상세 문의를 원하시면 -> Click 또는 02-2659-9948 / kri@k-ri.co.kr
