AGA - Advanced Grazing Angle Specular Reflectance

.  Small areas of thin films, mono-molecular layers 정량분석

.  고정 입사각: 80도

.  Selectable sample dimensions as small as 1/8″ and as large as 1/2″

.  스펙트럼 범위: 10,000-500 cm-1

기본구성

.  10015-10XX AGA - Grazing Angle Specular Reflectance Accessory includes 5 selectable spot sizes of 1/2", 3/8", 1/4", 3/16" and 1/8", gold substrate alignment mirror, polarizer mount and FTIR base mount

선택구성

.  Replacement parts and Sampling options

장비 관련 상세 문의를 원하시면 -> Click 또는 02-2659-9948 /  kri@k-ri.co.kr
