UV-Vis Calcite Polarizers
. Glan-Taylor 방식과 UV Glan-Thompson 방식 중 선택 가능
. Manual 방식과 Automated 방식 중 선택 가능
. Glan-Talyor and UV Glan-Thompson Designs
. 고급 방해석 사용
. 높은 소광비(Extinction Ratio)
. 표준 2 x 3 인치 마운트에 장착 가능
. Specifications
|
Glan-Taylor |
UV Glan-Thompson |
Material |
Calcite |
Calcite |
Spectral Range |
250-2300 nm |
250-2300 nm |
Clear Aperture |
12 mm |
14 mm |
Extinction Ratio |
5 x 10^-5 |
1 x 10^-4 |
Manual Polarizer Dimensions (W x D x H) |
29 x 50 x 146 nm |
49 x 50 x 146 mm |
Automated Polarizer Dimensions (W x D x H) |
56 x 50 x 146 nm |
56 x 50 x 146 mm |
Angular Resolution, Manual |
1° |
1° |
Angular Resolution, Auto |
0.5° |
0.5° |
기본구성
. 101981623 Manual Glan-Taylor
. 101981624 Manual UV Glan-Thompson
. 101981625 Automated Glan-Taylor
. 101981626 Automated UV Glan-Thompson
